FROM FAST, ROWDY DESCENTS TO TECHNICAL TERRAIN, THIS PROGRESSIVE TRAIL BIKE GIVES YOU ACTIVE SUSPENSION, ADJUSTABLE FRAME GEOMETRY, AND EVERYTHING YOU NEED TO UP YOUR SINGLETRACK GAME.
KEY PERFORMANCE FACTORS
29er confidence and control
29-inch wheels optimized to roll over technical terrain with balance and stability, giving you more momentum on tricky climbs and confidence to fly on fast singletrack descents. Added clearance for up to 2.5-inch tires.
Progressive suspension
Maestro rear suspension features a trunnion mount shock with a longer stroke and smoother feel. With 135mm of full rear-wheel travel (and 150mm up front), it features an Advanced Forged Composite upper rocker arm for increased stiffness and strength plus lower overall frame weight.
Adjustable geometry
A flip chip lets you change the headtube and seattube angles, along with the bottom bracket height, to fine-tune the handling. You can choose the low position (65.5/77.2 head/seattube angle and 40mm BB drop) for fast, open terrain, or high (66.2/77.9 head/seattube angle and 30mm drop) for slower, tighter singletrack.
| Size | Small, Medium, Large, X-Large |
|---|---|
| Chain | SRAM SX Eagle |
| Pedals | Sold Separately |
| Saddle | Giant Romero SL |
| Seatpost | Giant Contact Switch dropper, remote |
| Stem | Giant Contact SL 35 |
| Tape/Grips | Giant Tactal Pro Single |
| Handlebars | Giant Contact TR35, 780x35mm, 20mm rise |
| Brake Levers | Shimano Deore BL-MT401 |
| Rotors | Front: Shimano RT-66 203mm rotor Rear: Shimano RT-66 180mm rotor |
| Brakes | Shimano Deore BR-MT420, hydraulic |
| Cassette/Freewheel | SRAM SX, 11×50 |
| Color | Phantom Green |
| Rear Derailleur | SRAM SX Eagle |
| Shifters | SRAM SX Eagle, 1×12 |
| Crankset | SRAM SX, 30t |
| Bottom Bracket | SRAM DUB, press fit |
| Tires | Front: Maxxis Minion DHF 29×2.5 WT, 3C MaxxTerra, EXO, TR Rear: Maxxis Aggressor 29×2.4, EXO, TR, tubeless |
| Wheels | Giant TR 1 29 WheelSystem |
| Rear Shock | Fox Float DPS Performance, 185/55, custom tuned for Giant |
| Fork | Marzocchi Z2, 150mm, Rail damper, Boost 15×110 Kabolt, 44mm offset, custom tuned for Giant |
| Frame | Advanced-Grade Composite front and rear triangles, 135mm Maestro suspension, flip chip, 12x148mm thru-axle |
| Accessories & Extras | tubeless prepared, 2.5" max tire size, 34t max chainring size, 3M tailgate protector |
